Diamond Core Drill Rig DBE 201
- Drilling Diameter: Up to 8″
- Load Speeds: 450 RPM
- Power: 18 Amp
- Wet Drilling
Includes (testing):
- DBE 201 Drill Motor and Rig
- Open Wrench SW 32 + 41
Benefits
- Industry's most powerful, compact, and lightweight core drill rig, the drill motor, integrated water supply, and rig weight only 34 lbs., making the DBE 201 a portable and easy to maneuver machine.
- Built from corrosion resistant, high strength materials to withstand daily use in tough environments.
- High durability engineering includes features such as an oil bath gearbox for optimal lubrication and longer tool life, a stainless steel spindle, motor overload protection, and spring loaded carbon brushes, also for motor protection.
- Heavy duty column and base provide exceptional rigidity for straight, accurate coring. Anchor mounted stand for easy drilling, reducing operator fatigue.
- Supports demanding structural concrete drilling applications, designed for large 8" dia. concrete drilling capacity, with the best power to weight ratio in the industry.
- Ergonomic design with increased safety for operator including mechanical safety slip clutch and GFCI overcurrent protection.
- This core drill rig delivers increased safety, productivity, and user comfort.
Applications & Usage
- Diamond Core Drill Rig for wet drilling up to 8″ dia. in reinforced concrete, concrete, natural stone, and asphalt.
- Ideal for plumbing, mechanical and electrical construction, as well as civil engineering and landscape construction.
- For drilling on floors, walls, and overhead/ceilings.
- Lightweight and streamlined design makes it extremely portable and easy to maneuver for any concrete drilling application.
- Drills accurate holes for service entrances, conduit banks, cable trays, and utility penetrations.
- Suitable for extracting large concrete core samples for engineering analysis, quality control, and structural assessment.
- Supports coring for bridges, tunnels, foundations, utility vaults, and infrastructure projects.
Technical Specifications
| Item ID: DBE 201 | |
| Power input | 18 Amp |
| Rated Voltage | 110 V |
| Load Speeds (RPM) | 450 |
| No-Load Speed (RPM) | 675 |
| Drilling Diameter | 8" |
| Spindle Connection | 1-1/4"x7 UNC, 5/8"x11 UNC (optional) |
| Column Length | 31" |
| Hub | 21-3//4" |
| Weight | 34 lbs. |
| Package Contents | In a box DBE 201 motor and rig, open wrench SW 32 + 41 (diamond core drill bit not included) |
| * DBE 200 has been discontinued and is replaced by DBE 201 | |
Optional Accessories
