NEW eMAB 450 – Battery Powered
- Cutting Capacity: 1-9/16″ Diameter
- Twist Drill Capacity: 7/8″ Diameter
- Stroke: 5-5/16″
- 5 Speed Motor
Benefits
- Battery powered, cordless magnetic drill. The next generation of drilling freedom!
- Portable design makes it easy to carry between job sites or elevated work areas.
- High-efficiency, brushless, copper motor for long tool life and low maintenance.
- Strong, permanent magnetic with reversible rotation.
- High quality machine made in Germany.
Applications & Usage
- eMAB 450 is a battery powered machine for onsite drilling for equipment repair, retrofits, and facility maintenance.
- Useful in plants, warehouses, and industrial buildings.
- Drilling mounting holes for conduit supports, cable trays, HVAC brackets, and mechanical systems.
- Vertical and horizontal drilling on I‑beams, channels, and steel frameworks.
- Suitable for installing brackets, supports, and bolted connections.
- See Recommended Speed and Feed Charts for Annular Cutters
Technical Specifications
| NEW Item ID: eMAB 450 | |
| Motor Power | 1000 W |
| Weight | 25.4 lbs. (w/o Battery) |
| Stroke | 5-5/16" |
| Hole Capacity | 1-9/16" dia. |
| Twist Drill Capacity | 11/16" dia. |
| Speeds | 134, 189, 246, 298, 355 RPM |
| Magnet Base Size | 6-5/8” L x 3-1/3” W |
| Dimensions | 14.2" H x 12.2" L x 9.6" W |
| Spindle Taper | Direct Arbor |
| Automatic Lubrication | Included |
| Battery Type | Li-Ion 18 V / 10.4 Ah / 187 Wh |
Optional Accessories
Optional
OptionalDiameter: Kit • Depth: 2 3/8"
$0.00
In stock
Optional
OptionalConnection: 3 flats x 3/4" arbor • Size: 2 1/8" length, 1/2" shank
$0.00
In stock
Optional
OptionalRelated PDFs
Catalog PDF
SPEC_EMAB450
Download PDF
Usage
- eMAB 450 is a battery powered machine for onsite drilling for equipment repair, retrofits, and facility maintenance.
- Useful in plants, warehouses, and industrial buildings.
- Drilling mounting holes for conduit supports, cable trays, HVAC brackets, and mechanical systems.
- Vertical and horizontal drilling on I‑beams, channels, and steel frameworks.
- Suitable for installing brackets, supports, and bolted connections.
- See Recommended Speed and Feed Charts for Annular Cutters
Benefits
- Battery powered, cordless magnetic drill. The next generation of drilling freedom!
- Portable design makes it easy to carry between job sites or elevated work areas.
- High-efficiency, brushless, copper motor for long tool life and low maintenance.
- Strong, permanent magnetic with reversible rotation.
- High quality machine made in Germany.
Usage
- eMAB 450 is a battery powered machine for onsite drilling for equipment repair, retrofits, and facility maintenance.
- Useful in plants, warehouses, and industrial buildings.
- Drilling mounting holes for conduit supports, cable trays, HVAC brackets, and mechanical systems.
- Vertical and horizontal drilling on I‑beams, channels, and steel frameworks.
- Suitable for installing brackets, supports, and bolted connections.
- See Recommended Speed and Feed Charts for Annular Cutters
Benefits
- Battery powered, cordless magnetic drill. The next generation of drilling freedom!
- Portable design makes it easy to carry between job sites or elevated work areas.
- High-efficiency, brushless, copper motor for long tool life and low maintenance.
- Strong, permanent magnetic with reversible rotation.
- High quality machine made in Germany.
